TP-Link L3 M. Switch, 24x1G,4x combo,2+2 10G SFP+

Kalkulačka splátek CETELEM
52436 Kč s DPH

43336 Kč bez DPH
Dostupnost: Nedostupné
Part no.: T3700G-28TQ
Výrobce: TP-Link
Záruka: 24 měsíců
TP-Link L3 M. Switch, 24x1G,4x combo,2+2 10G SFP+
Produkt je zařazen:

Popis produktu:
TP-Link L3 Managed Switch, 24x1G,4x combo,2+2 10G SFP+

OVERVIEW
* Abundant Layer 3 routing protocols including RIP/OSPF/ECMP/VRRP that support a scalable network
* True Physical Stacking technology supports up to 8 units and 320Gbps backplane bandwidth for high scalability and efficient redundancy
* 10 Gigabit Ethernet uplink provides high-bandwidth applications for congestion relief and smooth data delivery
* Removable power unit and redundant power supply functionality minimizes downtime
* PIM-SM/PIM-DM/IGMP Snooping for resilient video deployments


SPECIFICATIONS
HARDWARE FEATURES
Standards and Protocols
* IEEE 802.3i, IEEE 802.3u, IEEE 802.3ab, IEEE802.3z, IEEE 802.3ae, IEEE 802.3ad, IEEE 802.3x, IEEE 802.1d, IEEE 802.1s, IEEE 802.1w, IEEE 802.1q, IEEE 802.1x, IEEE 802.1p

Interface
* 24 10/100/1000Mbps RJ45 Ports (Auto Negotiation/Auto MDI/MDIX)
* 4 combo gigabit SFP Slots
* Up to 4 10G SFP+ Slots (2 fixed and 2 optional 10G SFP+ Slots)
* 1 Console Port

Network Media
* 10BASE-T: UTP category 3, 4, 5 cable (maximum 100m)
* 100BASE-TX/1000Base-T: UTP category 5, 5e or above cable (maximum 100m)
* 100BASE-FX: MMF, SMF
* 1000BASE-X: MMF, SMF
* 10GBASE-LR
* 10GBASE-SR

Dimensions (W X D X H)
* 440*330*44 mm

Fan Quantity
* 4

Power Consumption
* 63W (220V/50Hz) max

Power Supply
* 100~240VAC, 50/60Hz

PHYSICAL STACKING
Installable SFP+ Transceivers and Direct Attach Copper (DAC) Cables
* TXM431-SR
* TXM431-LR
* TXC432-CU1M
* TXC432-CU3M

Max Number of Stacking Ports Installable
* 2 SFP+

No. of Units Per Stack
* 8

Stacking Speed (Per Port)
* 20 Gbps (Full-Duplex)

PERFORMANCE
Switching Capacity
* Up to 128Gbps for a standalone switch

Bandwidth/Backplane
* Up to 320Gbps when 8 units in the stack

MAC Address Table
* 32K

Packet Buffer Memory
* 16 Mbits

Packet Forwarding Rate
* Up to 95.2Mpps for a standalone switch

Jumbo Frame
* 10240 Bytes

Number of IP Interfaces
* 128

Number of Routes
* 12K

Number of Static Routes
* 256

SOFTWARE FEATURES
L3 Features
* Wire-speed IP forwarding
* Static Routing
* RIP v1, v2
* OSPF v2
* ECMP
* PIM-SM/PIM-DM/IGMP
* DHCP Server/Relay
* ARP Proxy
* VRRP

Quality of Service
* Support 802.1p CoS/DSCP priority
* Support 8 priority queues
* Queue scheduling: SP, WRR, SP+WRR
* Port/Flow- based Rate Limiting
* Voice VLAN

L2 Features
* IGMP Snooping V1/V2/V3
* 802.3ad LACP (Up to 32 aggregation groups, containing 8 ports per group)
* Spanning Tree STP/RSTP/MSTP
* BPDU Filtering/Guard
* TC/Root Protect
* Loop back detection
* 802.3x Flow Control

VLAN
* Supports up to 4K VLANs simultaneously (out of 4K VLAN IDs)
* IEEE 802.1Q VLAN/MAC VLAN/Protocol VLAN/QinQ/Private VLAN/GVRP

Access Control List
* L2~L4 package filtering based on source and destination MAC address, IP address, TCP/UDP ports, 802.1p, DSCP, protocol and VLAN ID
* Time Range Based

Security
* IP-MAC-Port-VID Binding
* IEEE 802.1X Port/MAC Based authentication, Radius,Guest VLAN
* DoS Defence
* Dynamic ARP inspection (DAI)
* SSH v1/v2
* SSL v2/v3/TLSv1
* Port Security
* Broadcast/Multicast/Unknown-unicast Storm Control

Management
* Web-based GUI and CLI management
* SNMP v1/v2c/v3,compatible with public MIBs and TP-LINK private MIBs
* RMON (1, 2, 3, 9 groups)
* DHCP/BOOTP Client, DHCP Snooping, DHCP Option82
* CPU Monitoring
* Port Mirroring
* Time Setting: SNTP
* Integrated NDP/NTDP feature
* Firmware Upgrade: TFTP & Web
* System Diagnose: VCT
* SYSLOG & Public MIBS
* Dual Image

OTHERS
Certification
* CE, FCC, RoHS

Package Contents
* Switch; Power Cord; Quick Installation Guide; Resource CD; Rackmount Kit; Rubber Feet

System Requirements
* Microsoft® Windows® 98SE, NT, 2000, XP, Vista™ or Windows 7/8, MAC® OS, NetWare®, UNIX® or Linux.

Environment
* Operating Temperature: 0°C~40°C
* Storage Temperature: -40°C~70°C
* Operating Humidity: 10%~90% non-condensing
* Storage Humidity: 5%~90% non-condensing
